I have powered off/on the whole PL4/S2IPA and my router several times and I have reset the S2IPA several times but still no worky.So it looks to me like the S2IPA is not getting an IP address (in the 10.x.x.x range that my router uses for my internal network), yet by default the S2IPA is supposedly set to DHCP. I check my Router Logs and I don't see the device S2IPA at all.I am typing in the correct correct system name, "Pentair: XX-XX-XX", where XX-XX-XX represents the characters that are written on my S2IPA I didn't type XX-XX-XX.When I run the ScreenLogic Connect software on my PC I get an error "System Not Found" I have a proper red light on the S2IPA so it is powered from the PL4 com port J20Ĥ.

I have triple checked all wires and connections.

My router assigns it a 10.x.x.x address through DHCP to the PC.

I have previously tested this LAN connection with a PC (which is set to use DHCP just like the S2IPA supposedly defaults to use as well) and it connects to the network and internet just fine.

The S2IPA is connected directly to my router by wired (CAT6) LAN RJ-45 cable and lights show I have a 10/100 connection on the router I have hardwired it correctly(J20 Com Port - 4 wires) to the ScreenLogic2 Interface Protocol Adapter (S2IPA).ģ. I have an Pentair EasyTouch PL4 control panel.Ģ.
